Optimization of design and mode parameters of the well ejection system

Authors

  • Ye. I. Kryzhanivskyy Ivano-Frankivsk National Technical University of Oil and Gas, 15 Karpatska Street Ivano-Frankivsk Ukraine, 76019
  • D. O. Panevnyk Ivano-Frankivsk National Technical University of Oil and Gas, 15 Karpatska Street Ivano-Frankivsk Ukraine, 76019

DOI:

https://doi.org/10.31471/1993-9868-2020-1(33)-73-80

Abstract

Insufficient energy performance of ejection equipment and a high probability of non-operating modes of its operation reduce the efficiency of downhole jet pumps. The method of determining the design and operating parameters of the well ejection system, which provide the maximum efficiency of the jet pump, is presented.  The proposed algorithm for determining the optimal values of the geometric dimensions of the flowing part of the jet pump involves the construction of a series of pressure characteristics for different values of its geometric parameter, the calculation of the efficiency and the determination of the injection ratio and the relative pressure corresponding to its maximum values.  During the studies, the main geometric parameter of the jet pump varied in the range from
2 to 6, given that these geometric dimensions are used in jet devices common in the oil industry. The optimal dimensions of the current part of the jet pump are obtained in the process of studying its pressure characteristics, and the optimal dimensions of the washing system of the bit - in the process of studying the characteristics of the hydraulic system. The design of an at-bit ejection system, which allows to increase the mechanical drilling speed, the passage of the bit, to stabilize the moment on the bit, to reduce its level of vibration and to control the antiaircraft angles of the well is considered. The efficiency of using at-bit jet pumps is in the following: an increase in the mechanical drilling speed up to 18.7%, the passage of the bit up to 50.8%. The research established the optimal diameters of the working nozzle, mixing chamber and bit nozzles, the distance between the working nozzle and the mixing chamber, the injection ratio and the relative pressure of the at-bit jet pump. The obtained values ​​of design and mode parameters exclude the occurrence of cavitation modes of operation of the ejection system and allow the operation of jet pumps with maximum efficiency.
